Quantitative Characterization of Nanostructured Materials with Fast TKD Measurement

On-Demand Session - 45 Minutes

 eFlashFS EBSD Detector with OPTIMUS™ TKD

This webinar will discuss the quantitative characterisation of nanostructured material using the eFlashFS EBSD detector retrofitted with the OPTIMUS™ TKD head.

Significant improvements in light sensitivity and CCD dark current make the new Fast and Sensitive e–FlashFS detector the perfect solution for Transmission Kikuchi Diffraction (TKD) in SEM.

Using application examples, we will demonstrate how fast TKD measurements are achieved on different materials, without compromising the spatial resolution. When retrofitted with OPTIMUS™ TKD detector head, e–FlashFS detector enables orientation mapping at the nanoscale at speeds of up to 630 frames/sec.

The webinar will be round off by a 15-minute Q&A session where our experts will answer your questions.

For TKD with best sample-detector geometry: e-Flash FS with horizontal OPTIMUS detector head.
Raw orientation TKD map (IPFz) of Pt thin film on Si measured at 328 fps with 4 nm resolution.

Who Should Attend?

  • All-level users interested in characterization of nanostructured material
  • Researchers and specialists interested in Dark Field & Bright Field imaging as well as orientation mapping at the nanoscale
  • FIB/SEM microscopists interested in advanced analytical techniques


Dr. Daniel Goran

Product Manager EBSD, Bruker Nano Analytics

Dr. Laurie Palasse

Global Application Manager, Bruker Nano Analytics
