Crystallography

D8 QUEST

Modular, Single-Wavelength Platform for Single-Crystal X-ray Diffraction

The D8 QUEST is a modular and compact single-wavelength diffractometer designed for use in any lab performing routine and standard crystallography.

 D8 QUEST platform crystallographers can create a diffractometer that matches their research goals and available budget. The units modular design means future capability and performance upgrades can be easily made should your experimental requirements change.

The D8 QUEST uses best-in-class components and is available with air cooling to ensure the collection of the high-quality diffraction data for accurate structure determination.

  • Detector: PHOTON IV  with higher quantum efficiency than silicon-based detectors.
  • X-ray sources:

                -  Sealed-tube water-cooled X-ray sources for the Economy Class.

                -  Sealed-tube microfocus X-ray sources: IµS 3.0, for the Efficiency Class.

                -  Diamond-hybrid microfocus X-ray sources: IµS DIAMOND II, for the Performance Class.

  • Advanced safety enclosure: TUEV certified safety enclosure.
  • Software: APEX - the most comprehensive software suite available for chemical crystallography.

The D8 QUEST platform for crystallography can be configured to match your labs budget and analytical requirements.

Contact an Expert Build Your Own D8 QUEST
The D8 QUEST platform for crystallography can be configured to match your labs budget and analytical requirements.

Flagship Configurations of the D8 QUEST

Our two pre-configured D8 QUEST diffractometers - the D8 QUEST ECO and D8 QUEST GX - come as ready-built packages for single crystal X-ray diffraction.

ECONOMY

D8 QUEST ECO

For chemical research and education.

An accessible, easy-to-use diffractometer designed for teaching laboratories and routine chemical crystallography, delivering reliable structures with minimal setup and training.

Discover D8 QUEST ECO
Efficiency

D8 QUEST GX

Chemical Crystallography Made Effortless.

A compact, walk-up system with a high brilliance Mo IμS 3.0 microfocus source for fast, reliable results every day.

Discover D8 QUEST GX

Configure Your Own D8 QUEST

The D8 QUEST can be built custom according to your lab's specific needs, with your choice of source technology, goniometer, software, devices for non-ambient crystallography and more.

Available Technologies for the D8 QUEST

Detector

PHOTON IV Detectors

PHOTON IV is Bruker's Charge-Integrating Pixel Array Detector (CPAD) for single crystal X-ray diffraction.

Available with either a 8,000 mm2 or 16,000 mm2 active area.

Learn more
X-Ray Source

1 kW Sealed-Tube Source

Our water-cooled sealed tube X-ray source delivers excellent intensity with low investment and maintenance needs. Perfect for chemical crystallography with large and medium sized crystals or for teaching needs.
Learn more
X-ray source

IµS 3.0 Microfocus Source

The IµS 3.0 is the first-ever microfocus source designed from the ground up for crystallography, significantly outperforming the intensity of microfocus sources based on conventional tube technology.
Learn more
X-ray Source

IμS DIAMOND II Hybrid-Anode Source

The IµS DIAMOND II uses patented diamond-hybrid-anode technology to generate beams of the intensity and brilliance needed for demanding crystallography.
Learn more
Goniometer

Automated Goniometer Head

The Automated Goniometer Head (AGH) uses X-ray-based software centering to automatically locate and align the best-diffracting region of a crystal to the goniometer centre.
Learn more
Goniometer

XYZ Goniometer Head

The XYZ Goniometer Head provides manual three-axis translational positioning for sample mounting on Bruker single-crystal diffractometers.
Learn more
Software

APEX

APEX is a complete crystallography software solution - from instrument control to structure publication - with exceptional data processing and features including AI-based crystal centering and automated CIF report generation.

Suitable for both novice and experienced crystallographers.

Learn more
Software

PROTEUM

Crystallography software for the entire measurement process - from instrument control through to screening, solving structures and report generation - designed specifically for life science applications.
Learn more
Non-Ambient Crystallography

High-Pressure Kit

The High-Pressure Kit is a fully integrated solution for single-crystal X-ray diffraction experiments under extreme conditions using a Diamond Anvil Cell (DAC).
Learn more
Non-Ambient Crystallography

Low Temperature Devices

Bruker's range of fully integrated low-temperature devices enable crystallography from 28 K to 500 K.

Options include the nitrogen-cooled Cryostream 1000, the liquid-nitrogen-free Cobra 1000, and the N-HELIX for ultra-low temperature experiments.

Learn more

Build Your Own Diffractometer Using the Configurator

Use our configurator to build your own custom diffractometer with specifications matched to your laboratory needs.

First choose which diffractometer class you are interested in:

Economy class diffractometer logo. 1/5

Configurator: Economy Solutions

Great Results with Minimal Investment.

Our Economy Solutions are designed for teaching laboratories and routine chemical crystallography, delivering reliable structures with minimal training and cost.

Choose between Mo or Cu radiation.

Build an Economy Class Diffractometer
Efficiency class diffractometer logo. 2/5

Configurator: Efficiency Solutions

Superior Results and Increased Productivity.

Our Efficiency Solutions for Crystallography feature a IμS 3.0 microfocus source (Cu, Mo, Ag) built specifically for crystallography to deliver a high intensity while keeping operating costs down.

Choose between Ag, Mo or Cu radiation.

Build an Efficiency Class Diffractometer
Performance class diffractometer logo. 4/5

Configurator: Performance Solutions

For Demanding Crystallography.

Our Performance Solutions for Crystallography use a patented diamond-hybrid-anode source to generate intense and brilliant beams for applications that require high speed and precision.

Choose between Ag, Mo or Cu radiation.

Build a Performance Class Diffractometer

Learn More About the D8 QUEST

Webinars: Single-Crystal X-ray Diffractometry

Brochures: D8 QUEST Configurations



Brochures: SC-XRD Product Range

Application Notes

Testimonials

The D8 QUEST is a favourite of crystallography labs worldwide. To learn more about what our customers think of our systems and technology view our testimonials page.
