Oil and Gas: Exploration Upstream

Produced Water, EH&S and Environmental Analysis

Environmental stewardship has evolved into a core mission for operators. Working in remote or inaccessible environments with requirements for frequent monitoring means special analytical challenges. Bruker’s rugged solutions are ready to meet the challenge.

EH&S in Oil and Gas

Bruker is Your Partner for Environmental, Health and Safety Detection and Analysis

Safety and environmental responsibility have become core missions of the oil and gas industry, particularly as exploration and production explores new frontiers. Key missions include the protection of life and property, human health and safety, spill protection and response, and managing discharge. Bruker provides a wide range of tools used to manage environmental and safety detection requirements from offshore to unconventional.

Oil in Water

Oil in Water Analysis for Off-Shore Platforms

Wherever oil and grease are handled industrially and on a larger scale (e.g. offshore oil-rigs) their discharge into the environment should be tested. To analyze and extract oil and grease from water highly flammable solvents such as pentane or hexane are used in current standard methodology.  

Of course, the use of these solvents on oil platforms is not permitted and the water samples must be transferred to a mainland lab. While infrared spectroscopy is widely used for traditional oil content determination, it also offers the opportunity to avoid costly and time-consuming transportation by using solid phase extraction. 

The ASTM approved” Standard test method for solvent-free membrane recoverable oil and grease by Infrared determination D7575” is such a convenient alternative. In short, this method quantifies oil and grease by processing a water sample through an oil capturing membrane and analyzing the membrane – no hazardous or flammable solvents are involved. 

By doing this, the analysis time including sampling and measurement is reduced to less than 15 minutes for most samples. Using parallel processing allows for processing many samples simultaneously. 

Infrastructure Protection and HAZMAT

Infrastructure Protection and HAZMAT

The detection, identification, and mitigation of hazardous materials and explosives has become mission critical for oil and gas operators.   Oil and gas production and processing is critical infrastructure and has a requirement for rapid response to incidents, including substance identification. Bruker’s environmental and detection solutions provide workflow-centric and easy to use HAZMAT and CBRNE hazard detectors and instrumentation.

Positive Material Identification

Positive Material Identification

Positive Material Identification (PMI) is the identification of the alloy for mission critical parts. Bruker’s portable XRF (pXRF), optical emission spectroscopy (OES), and laser induced breakdown spectroscopy (LIBS) are used to ensure the correct alloy is installed for high-temperature or high-pressure parts. This critical safety step prevents blowouts, critical failures, and saves lives.

Heavy Elements in Produced Water

Heavy Elements in Produced Water

Total reflection X-ray fluorescence (TXRF) brings the ability for on-site analysis of heavy elements in water to any location from offshore rigs to a rig-side tailgate. Detection limits down to ppb range can be achieved with no dilution, no consumable gas, and simple sample preparation. TXRF is an ideal method for testing produced water, offshore wastewater, soil and other liquids or dissolved solids for heavy metals like cadmium (Cd), mercury (Hg) and Selenium (Se).

Zugehörige Produkte

Products for Produced Water and Environmental Analysis

G4 ICARUS Series 2

G4 ICARUS Series 2

The combustion analyzer G4 ICARUS Series 2 with HF induction furnace and HighSenseTM detection is the ideal instrument for the rapid and precise carbon and sulfur determination in solids, especially metals and their alloys as well as other inorganic materials like ores, cements, minerals, ceramics, etc.
MATRIX-F - online FT-NIR Spectrometer

MATRIX-F - online FT-NIR Spectrometer

Online FT-NIR spectrometer for the direct measurement in reactors and pipelines, for a better understanding and control of the process
MPA II Dairy Analyzer

MPA II Dairy Analyzer

From raw milk to finished dairy products - test the full range along the production chain with just one easy-to-use FT-NIR analyzer.
S1 TITAN Hamdheld XRF Analyzer

S1 TITAN Handheld XRF Analyzer

Handheld XRF ideal for taking the lab to the sample for fast analysis of any material: small, light-weight (<1.5 kg with battery), preloaded with point-and-shoot calibrations of choice.
S2 PUMA Series 2

S2 PUMA

Multi-element analysis from Carbon (C) to Americium (Am) for a wide range of applications in at-line quality control or in central labs. With its unique HighSense detectors the S2 PUMA also masters advanced applications in R&D.
S4 T-STAR TXRF spectrometer

S4 T-STAR

High-volume TXRF spectrometer for ultra-trace (sub-ppb) elemental analysis of very small sample amounts in the pg, ng or µg range: low operating cost, “green” technology
TANGO - Standalone FT-NIR Spectrometer

TANGO - Standalone FT-NIR Spectrometer

Proven technology combined with an easy-to-use touch screen operation and a small footprint, perfect for laboratories with limited space.
