Quantification of Steels and Alloys using a dual source multidetector system. Part II: SEM-WDS adding to XRF-EDS and SEM-EDS analysis

This webinar took place on April 29, 2021


Quantification of steels and alloys can be problematic due to the various elements of interest and the range of concentrations present from majors through to traces.  This two-part webinar will show the benefits of using a dual-beam system, that is, a system that has both an electron and micro-XRF source.  In addition, this system is equipped with an energy dispersive spectrometer (EDS) and a wavelength dispersive spectrometer (WDS).  Preceding Part I of this webinar series focused on the dual-beam sources, and the respective advantages of electron and photon excitation for X-ray analysis.  Part II will now compare these results with the measurements using the WDS collected on the same system.  We will show that WDS adds value to the combined analysis when certain trace elements or light elements are of interest, when peak overlaps are present or when high spatial resolution is required. The samples used for this webinar are a range of certified steels with variable concentrations of Cr and Ni, expected for those used in industry, as well as quantifying minor and trace elements, like Cu, Mo, S, Si, Al, P, N and C.  The results demonstrate the capabilities and benefits of using a dual source multi detector system. The webinar will be rounded off by a 15-minute Q&A session where our experts will answer your questions.

SEM with various micro-XRF source attached (right) with EDS (left), WDS (back) and FQ-EDS (bottom right)
X-ray element distribution map for C and Fe acquired on a dual phase steel. (sample courtesy of TU Eindhoven)

Who should attend?

  • Everyone dealing with an application where quantification is required
  • Researchers from industry and academia who investigate steels or alloys


Stephan Boehm

Product Manager micro-XRF / SEM and WDS, Bruker Nano Analytics

Dr. Michael Abratis

Sr. Application Scientist, Bruker Nano Analytics
