StretchingStage for Higher Forces
Enables sample property changes under external mechanical load up to 5,000 N or 10,000 N.
- Stand alone stage with integrated sample stretching and compression capabilities
- Force range: 10 N and 5,000 N (10,000 N avail.) exchangeable load cells
- Maximum travel range: 40mm for samples of 5mm length between jaws (resolution 100nm)
- Velocity: 0.006 to 3 mm/min
- Not compatible with inverted microscopes
- Motor power: 20 W
