StretchingStage for Higher Forces
Enables sample property changes under external mechanical load up to 5,000 N or 10,000 N.
- Stand alone stage with integrated sample stretching and compression capabilities
- Force range: 10 N and 5,000 N (10,000 N avail.) exchangeable load cells
- Maximum travel range: 40mm for samples of 5mm length between jaws (resolution 100nm)
- Velocity: 0.006 to 3 mm/min
- Not compatible with inverted microscopes
- Motor power: 20 W
Accessories to extend your BioAFM capabilities
Bruker offers an extensive range of BioAFM system add-ons, accessories, and modes to deliver maximum experimental and sample control, superior versatility, and enhanced useability. These options extend the range of applications and experiments supported by Bruker BioAFMs far beyond what is possible with any other BioAFM system on the market today.
Available options include optical systems/accessories, electrochemistry solutions, electrical sample characterization, environmental control options, software modules, temperature control, acoustic and vibration isolation solutions, and more.
Download our accessories handbook to learn more.
