nanoElute® 2

The nanoElute® 2 is a high-performance nanoflow liquid chromatography system with an intuitive and flexible user interface, covering a broad range of applications from single cell to high throughput routine proteomics.

Robustness and performance without compromise

Premium liquid chromatography-mass spectrometry data quality relies on the robust nanoElute® 2 separation system

Highlights

LIQUID CHROMATOGRAPHY

nanoElute® 2

Performant
Ultra-sharp peaks for the best proteomics performance
Flexible
Flexible user-controlled features and injection modes
Robust
Unprecedented reproducibility and robustness achieved with improved pump design
User friendly
User friendly interface for early-adopters and assisted troubleshooting procedures for expert users

Features

nanoElute® 2

Built on the core principles of its predecessor, the nanoElute® 2 has been refined for unrivalled robustness, ultimate chromatographic performance, and ease-of-use.

  • Unprecedented pump reproducibility and robustness
  • Ultra-sharp peaks for the best proteomics performance
  • Flexible user-controlled features and injection modes
  • User friendly interface for early-adopters
  • Assisted troubleshooting procedures for expert users
  • Automatable sample preparation workflows
  • Reach extreme LC-MS sensitivity for “label-free single-cell level” workflows



The nanoElute® 2 covers a broad range of applications from single-cell to high-throughput routine proteomics. This next generation system provides you with the highest chroma­tographic resolution resulting in exceptional peptide identification and quantification.

Robust chromatography Overlayed extracted ion chromatograms (27 peptides) of 10 consecutive injections. 20 fmol BSA tryptic digest (Bruker Daltonics 8217498) have been injected onto a PepSep TWENTY-FIVE column (Part No. 1893476, 150 μm ID, 1.5 μm particle size) and separated by a 10 min gradient.

Benefits

Unprecedented reproducibility and robustness

Unprecedented reproducibility and robustness achieved with:

  • New, hardened switching valves, for extended lifetime
  • Improved pump design
  • Finger-tight, torque-limiting capillaries, for leak-free, zero dead volume connections, without risk of overtightening or damaging capillaries.
Stable retention times across hundreds of injections (A) Extraction of 8 peptides (400 consecutive injections). 20 fmol BSA tryptic digest (8217498) have been injected onto a PepSep FIFTEEN column (Part No. 1895814, 75 μm ID, 1.9 μm particle size) and separated by a 10 min gradient. (B) Boxplot for median-normalized retention times show an average retention time deviation for each of the 8 peptides of < 2 sec.

Ultra-sharp peaks and best proteomics performance

The nanoElute® 2 provides precise and reproducible gradient separation for different gradient lengths, resulting in narrow peak widths and excellent peak capacity.

Reliable performance of 50 ng K562 digest injections at different gradient length (A) Corresponding boxplots with FWHM for eluting peaks indicate consistent and narrow peak widths and just a moderate increase for longer gradients. (B) Boxplot for protein group and precursor identifications dependent on gradient length (DDA-PASEF - timsTOF Pro 2, and PaSER™ realtime search engine with TIMScore).

In combination with the timsTOF HT reliable performance was achieved for all injected quantities (see Figure C). This within a 41 min runtime method for 1600 ng K562 tryptic digest by data dependent acquisition parallel accumulation serial fragmentation PASEF® (DDA).

Reliable performance for high peptide amount. More than 6800 protein groups identified using the PaSER™ realtime search engine with TIMScore™ for dda-PASEF of K562 tryptic digest with a PepSep Twenty-five series column (150 μm ID, 1.5 μm particle size) within a 41 min runtime on the timsTOF HT.

User-friendly and trouble-free chromatography

With its unique valve design the nanoElute® 2 enables software-controlled flow paths for dynamic inclusion of the trap column and backflushing the sample for sharper peaks. It retains the top desirable functionalities of its predecessor ensuring:

  • Dynamic on-the-fly method configuration
  • Efficient, predefined column washing and re-equilibration
  • Fully integrated and intelligent software-control
  • Built-in quality control and leak management
  • Seamless switch between trap-and-elute, direct load and direct infusion experiments

These features reduce the need to compromise between high performance, flexibility and robustness, therefore giving you full confidence in your results!

Fully automated self-testing and diagnosis is embedded into a user-friendly interface for early adopters, as well as assisted troubleshooting procedures for experts.

New procedures allow for step-by-step evaluation of flow-paths to readily locate potential issues for easy troubleshooting and maintenance.

Sample preparation procedures provide flexibility for user-defined performance evaluation, autosampler washing, and solvent exchange procedures.

Automatable sample preparation workflows

Automatable sample preparation procedures alleviate the need for manual intervention can be configured based on user-defined input settings. The following liquid handling functionalities provide the means to dissolve and mix samples just prior to LC-MS analysis:

  • Add from vial
  • Dissolve
  • Derivatize
Consistent sample preparation prior to injection. Base peak chromatogram of 100 ng K562 tryptic digest injected onto a PepSep Twenty-five series column (150 μm ID, 1.5 μm particle size). Peptides were resuspended in 0.001% DDM by the autosampler (dissolve) just prior to Injection (52589 +/- 1020 precursors identified). Peptides dissolved in 0.001% DDM in advance served as control (51475 +/- 699 precursors identified).

Applications

Optimized platform for challenging OMICS analysis

Reliable for low sample amount and single-cell applications. Identification of (A) 1400 to 7100 protein groups and (B) 7000 to 59,000 precursors from 62.5 pg to 32 ng HeLa tryptic digest within 45 min run time on a IonOpticks Aurora column (75 μm ID x 25 cm) (dia-PASEF® - timsTOF SCP, and PaSER™ realtime search engine with TIMScore™).

The timsTOF SCP in combination with the nanoElute® 2 UHPLC system achieves unprecedented sensitivity. About 4000 protein groups and over 22,000 precursors were identified from 1 ng of HeLa using a 80 min runtime method (i.e. gradient length of 66 min) and a data-independent acquisition parallel accumulation serial fragmentation (dia-PASEF®).

Extreme sensitivity for label-free single-cell level workflows

Use the nanoElute® 2 and the timsTOF SCP for end-to-end single cell label-free proteomics workflows. The nanoElute® 2 injects directly from the label-free proteoCHIP holder used in the cellenONE cell sorter. In this workflow up to 144 single cells can directly be transferred from the cellenONE to the nanoElute® 2 autosampler, after sorting and preparation, without pipetting steps, for ultra-sensitive proteomics analysis using the timsTOF SCP and TIMS-DIA-NN.

Fully automated label-free single cell proteomics workflow using the cellenONE with the lable-free proteoCHIP and with holder support in the nanoElute® 2 for ultra-sensitive single cell analysis on the timsTOF SCP and data analysis on the PaSER™ using TIMS-DIA-NN.
Repetitive injections of different peptide concentration (250 pg, 1 ng or 2 ng) of a HeLa cell lysate digest either injected from an autosampler vial (grey) or from the proteoCHIP (blue) (25 min total run time) with indicated volumes pipetted into each well show excellent reproducibility on protein group (A) and peptide (B) level.



Assessment of sample pick-up of 250 pg and 1 ng in 1 μL total volume, and 2 ng in 2 μL total volume of peptides from a HeLa cell lysate digest directly injected from wells of the label-free proteoCHIP showed excellent reproducibility in protein group and peptide identification rates. Injections from the label-free proteoCHIP and from an autosampler vial demonstrated comparable results on protein group and peptide identification rates at different peptide concentrations and volumes.
