▶ WATCH ON-DEMAND | 60 MINUTES

Scanning Probe Microscopy (SPM) Applications in Lithium-Ion Battery

Presented by Fangfang ZHAO, Ph.D., Applications Scientist, Bruker

Necessita de aceitar os cookies para reproduzir este vídeo.

Presented by Fangfang ZHAO, Ph.D., Applications Scientist, Bruker (September 29, 2021)

_{PRESENTATION HIGHLIGHTS}

[00:03:00] Introduction to lithium-ion battery technology, applications, and challenges
[00:08:26] How researchers use SPM for lithium-ion battery research (overview)
[00:13:00] Use Case: Structural characterization on battery separator
[00:16:00] Use Cases: Nanomechanical and nanoelectrical characterization on electrodes
[00:34:18] Use Cases: Solid Electrolyc Interface (SEI) characterization
[00:47:57] Other in-situ applications
[00:54:51] Live Q&A with the presenter
